渡槽传递窗是传递窗的一种，也叫药液传递窗，是通过液体消毒方式来进行灭菌的传递窗设备，对于不同的实验室要求，可分为普通级别渡槽和高等级生物安全渡槽，普通渡槽满足基本洁净要求即可，生物安全传递窗渡槽主要用于高等级生物安全实验室（BSL-3、BSL-4、ABSL-3、ABSL-4），具有气密性要求的房间，并具备解决物流通道的气密性问题。
产品特征
功能性：渡槽的用途与传递窗相似，但在结构上有所不同。它将物体浸没在消毒液中来进行消毒处理。
操作：使用渡槽时时，需要打开一侧的门，提起网格板放入物体，放下网格板使物体浸没在消毒液中，关闭门，并等待消毒过程完成。消毒完成，物体可以从对面取出。
互锁机制：渡槽具有双门互锁系统，确保在转移过程中不会破坏生物安全屏障。
材料兼容性：由304/316不锈钢制成，与多种消毒剂兼容，包括酚类、戊二醛类、季铵化合物、过氧化氢、醇类、碘化蛋白和次氯酸钠。
定制化：渡槽的尺寸可以根据特定用户要求进行定制，以适应不同大小和类型的材料。
生物安全协议：消毒剂的选择、补充时间表和所需浓度由现行的生物安全协议决定，确保渡槽的安全有效使用。
应用：渡槽广泛用于高级别实验室，如ABSL-3/4, BSL-3/4（生物安全等级3/4）的实验室，对危险生物制剂的控制至关重要的操作环境。
安全性和效率：渡槽为消毒热敏感材料提供了一种安全有效的方法，确保它们可以在实验室环境中安全地处理和加工。
The dunk tank is a type of pass box equipment that is sterilized through liquid disinfection. For different laboratory requirements, it can be divided into ordinary level dunk tank and high-level biosafety dunk tank. Ordinary dunk tank can meet basic cleanliness requirements, while biosafety duank tank are mainly used in high-level biosafety laboratories (BSL-3, BSL-4, ABSL-3, ABSL-4), rooms with airtightness requirements, And have the ability to solve the airtightness problem of logistics channels.
Product overview
Functionality:The trough's purpose is similar to that
of a transfer window, but its structure is different. It immerses objects in
disinfectant solution for disinfection treatment.
Operation: When using a trough, the side door needs to be opened, the grid
plate is lifted and placed in the object, the grid plate is lowered to immerse
the object in the disinfectant solution, the door is closed, and the
disinfection process is completed. After disinfection is completed, the object
can be taken out from the opposite side.
Interlock mechanism: The trough has a dual-door interlock system to ensure that
the biological safety barrier is not breached during transfer.
Material compatibility: Made of 304/316 stainless steel, it is compatible with
a variety of disinfectants, including phenols, glutaraldehyde, quaternary
compounds, hydrogen peroxide, alcohols, iodophor, and sodium hypochlorite.
Customization: The size of the trough can be customized according to the
specific requirements of the user to accommodate materials of different sizes
and types.
Biosecurity protocol: The selection of disinfectants, the schedule for
refilling, and the required concentration are determined by the current
biosecurity protocol to ensure the safe and effective use of the trough.
Application: The trough is widely used in high-level laboratories, such as
ABSL-3/4 and BSL-3/4 (biological safety levels 3/4) laboratories, where the
control of dangerous biological agents is critical. Safety and efficiency: The
trough provides a safe and effective method for sterilizing heat-sensitive
materials, ensuring that they can be safely handled and processed in a
laboratory environment.
